Concentric
Bolted
Connection
Allowable Capacity Analysis for
Staggered & Non-Staggered Connections
About This Project
The Concentric Bolted Connection Calculator computes the allowable capacity of bolted connections—both Staggered and Non-Staggered configurations—following AISC specifications and steel design standards. The analysis follows the Allowable Stress Design (ASD) approach to ensure safe and efficient structural connections.
The calculator performs comprehensive analysis including gross area capacity, bearing strength, shearing capacity, evaluates net area with staggered patterns, and block shear failure modes. It provides real-time validation and identifies the governing capacity based on the minimum of all failure modes.
Key Features
- AISC compliant calculations
- Gross area, bearing, and shearing capacity analysis
- Net area with staggered hole patterns
- Block shear failure mode evaluation
Academic Project
Developed by
Daryl Llona
Bicol University
College of Engineering
Class of 2025
Built With
Professional Bolted Connection Analysis
Comprehensive analysis of concentric bolted connections with allowable capacity calculations for all failure modes
AISC Compliant
Calculations based on AISC specifications and standard steel design methodology for bolted connections.
Multiple Failure Modes
Evaluates five critical failure modes including gross area, net area, bearing, shearing, and block shear with real-time results.
Staggered Pattern Support
Handles complex staggered bolt hole patterns with multiple path analysis for accurate net area calculations.
